CCR Series - 900 - 7000 Lumen LED Track Head

DOCUMENTATION:

INSTRUCTIONS:

Details

The CCR Series emphasizes efficiency and economy and boasts the highest lumens per watt rating of any Times Square Lighting fixture to date. It is designed for a short to medium throw applications. The CCR Series can be fitted with up to three accessories, including barn doors, louvers and lenses. This versatile fixture is available with a wide variety of mounting and dimming options, allowing for a huge range of customization possibilities.

The CCR is available in standard black, white, or silver finishes. Custom colors are available upon request.

LED

  • Cree XLamp LED array
  • Color temperature options: 2700K, 3000K, 3500K, 4000K, 5000K, 5700K, 6500K
  • CRI: 80 standard or 92 optional
  • Lumen maintenance: 90% of initial lumen output at 33,000 hours on LM-80 testing
  • No UV or IR

Electrical

  • Integral electronic driver
  • 100-277V, 50/60Hz
  • Meets FCC 47 CFR Part 15/18 Requirements

Construction

  • Steel & aluminum housing with black, white or silver finish
  • Accepts up to 3 accessories
  • Weight: 3 lbs.

Dimming

  • Trailing edge (ELV): 120V / 277V
  • Leading edge (Triac): 120V only
  • 0-10V: 120V only (ControlTrac), 120-277V otherwise
  • IP (Integral Pot) dimming available
  • Lutron ecosystem premier driver available, featuring dimming to 0.1% and soft on/soft off incandescent like dimming. Only available on fixtures 20 watts or less.


Additional Info

Track Surface Luminaires
≥ 1000
Trailing Edge
LED
~10° (Very Narrow)
Track
2700K
80+
