CR100CR100
9800 Lumen LED Accent Fixture
The CR100 is a powerful LED fixture designed for medium to long throw applications. This efficient, 80-watt LED fixture can produce a 12° degree beam that rivals line voltage PAR technology. The CR100 utilizes a Cree XLamp LED array that delivers a high lumen output and uniform color. At full 9800 lumen output, the fixture can be dimmed to 0.1% on 0-10V or 1% on phase dimming systems. The CR100 is available in Black, White, and Silver finishes. Custom colors are available upon request.
Resources
Fixture Type
- Integrated LED
LED Color
- Static White
Lumens
- 9800 Lm
CCT
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
- 5700K
CRI
- 80 CRI
- 92 CRI
Color / Finish
- Black
- Custom
- Silver
- White
Voltage
- 120 V
- 240 V
- 277 V
Distribution
- Flood (40° and Greater)
- Narrow Flood (20° - 39°)
- Spot (10° - 19°)
Mounting
- Pipe
- Stem
- Surface / Canopy
- Table Base
- Track
- Unistrut
Dimming Protocol
- 0-10 V
- DALI
- DMX
- ELV (Trailing Edge)
- Triac (Leading Edge)
Dimming Range
- 0-100%
Ratings & Compliance
- Build America Buy America Act (BABAA)
- IP20
- Made in America
Listings
- UL
Warranty
- 5 yr
Lamp Life
- 50000 hrs
