MKDW12

New Product

12-Watt Dim-to-Warm LED Track Head

Times Square Lighting’s Dim-to-Warm Series recreates the natural warm glow of incandescent light in a modern LED platform. Using a high-performance 12-watt Bridgelux Vesta DW LED, the fixtures deliver 1100 to 1300 lumens with a smooth color temperature transition to 1800K as they dim. Compatible with ELV, forward phase, or 0-10V dimmers, the Dim-to-Warm Series provides seamless integration into both new and existing control systems with no special drivers or programming required. Multiple beam spreads are available from a 12° spot to a broad 60° flood, with optional louvers, barndoors, and spread lenses. Available in black, white, silver, or custom finishes, this series is ideal for restaurants, hotels, spas, and other human-centric environments.
Specification Sheet

Resources

Fixture Type

  • Integrated LED

LED Color

  • Dim-to-Warm

Lumens

  • 1159 Lm
  • 1218 Lm
  • 1313 Lm
  • 1384 Lm

CCT

  • 2700K
  • 3000K

CRI

  • 90 CRI
  • 95 CRI

Color / Finish

  • Black
  • Custom
  • Silver
  • White

Voltage

  • 120 V
  • 240 V
  • 277 V

Distribution

  • Flood (40° and Greater)
  • Narrow Flood (20° - 39°)
  • Spot (10° - 19°)

Mounting

  • Pipe
  • Stem
  • Surface / Canopy
  • Table Base
  • Track
  • Unistrut

Dimming Protocol

  • 0-10 V
  • ELV (Trailing Edge)
  • Triac (Leading Edge)

Dimming Range

  • < 1%

Ratings & Compliance

  • Build America Buy America (BABA)
  • IP20
  • Made in America

Warranty

  • 5 yr

Lamp Life

  • 50000 hrs
