KL Fresnel FC

80W RGBMA LED 4” Fresnel w/ Zoom

The KL FRESNEL 4 FC™ is a full-color-spectrum LED fixture that provides high output, precise color temperature control, full-spectrum color rendering, and even wash coverage. Optimized for the tunable white light requirements of Film and Television, it is an ideal key and fill light source for many situations requiring outstanding performance and color quality, while offering a wide array of rich saturated colors and subtle pastels.

The KL FRESNEL 4 FC incorporates a highly efficient 5-in-1 (RGBMA) LED engine with a manual zoom range of 10° to 40°. Remotely adjustable LED refresh frequency makes this unit the perfect choice for today’s fast-paced production environments. Rugged and portable, the fixture can be mounted on a stand or suspended using any standard clamp. It is fully self-contained without the need for an external power supply and offers locking power pass-through for easy linking of multiple units.

The KL FRESNEL 4 FC can be operated through industry-standard DMX protocols and has full RDM support. In addition, it offers manual access using the included encoders and display, providing instant control of Intensity, Color temperature, Green shift, and other important settings. The display and encoders are conveniently positioned at the bottom side of the fixture to ensure unobstructed access while mounted on a stand.
Specification Sheet

Resources

Fixture Type

  • Fresnel
  • Integrated LED

LED Color

  • RGBW
  • Tunable White

Lumens

  • 2226 Lm

CRI

  • 92 CRI

Color / Finish

  • Black

Voltage

  • 100-240 V

Distribution

  • Adjustable Zoom

Mounting

  • Pipe
  • Surface / Canopy
  • Table Base
  • Track
  • Unistrut

Dimming Protocol

  • DMX

Dimming Range

  • 0-100%

Ratings & Compliance

  • IP20

Lamp Life

  • 50000 hrs
