ACR Series

900-2000 Lumen Cylinder Accent LED

The ACR Series emphasizes efficiency and economy and boasts the highest lumens per watt rating of any Times Square Lighting fixture to date. It is designed for a short to medium throw applications. The ACR Series can be fitted with up to three accessories, including barn doors, louvers and lenses. This versatile fixture is available with a wide variety of mounting and dimming options, allowing for a huge range of customization possibilities. The ACR Series is available in standard black, white, or silver finishes. Custom colors are available upon request.
Specification Sheet

Resources

Fixture Type

  • Integrated LED

LED Color

  • Static White

Lumens

  • 900 Lm
  • 1100 Lm
  • 1300 Lm
  • 1500 Lm
  • 1800 Lm
  • 2000 Lm

CCT

  • 2700K
  • 3000K
  • 3500K
  • 4000K
  • 5000K
  • 5700K
  • 6500K

CRI

  • 80 CRI
  • 92 CRI

Color / Finish

  • Black
  • Custom
  • Silver
  • White

Voltage

  • 120 V
  • 240 V
  • 277 V

Distribution

  • Adjustable Zoom
  • Flood (40° and Greater)
  • Narrow Flood (20° - 39°)
  • Spot (10° - 19°)

Mounting

  • Pipe
  • Stem
  • Surface / Canopy
  • Table Base
  • Track
  • Unistrut

Dimming Protocol

  • 0-10 V
  • DALI
  • ELV (Trailing Edge)
  • Triac (Leading Edge)

Dimming Range

  • < 1%

Ratings & Compliance

  • Build America Buy America Act (BABAA)
  • IP20
  • Made in America

Listings

  • UL

Warranty

  • 5 yr

Efficacy

  • 127 lm/w
  • 128 lm/w
  • 131 lm/w
  • 132 lm/w
  • 137 lm/w
  • 141 lm/w
  • 143 lm/w
  • 152 lm/w
  • 155 lm/w
  • 158 lm/w

Lamp Life

  • 50000 hrs
