CCR Series High PowerCCR Series High Power
4200-7000 Lumen LED Accent Fixture
The CCR Series High Power emphasizes efficiency and economy and boasts the highest lumens per watt rating of any Times Square Lighting fixture to date. It is designed for medium to long throw applications. The CCR can be fitted with up to three accessories, including barn doors, louvers and lenses. This versatile fixture is available with a wide variety of mounting and dimming options, allowing for a huge range of customization possibilities. The CCR is available in standard black, white, or silver finishes. Custom colors are available upon request.
Resources
Fixture Type
- Integrated LED
LED Color
- Static White
Lumens
- 4200 Lm
- 4600 Lm
- 4800 Lm
- 5200 Lm
- 5300 Lm
- 6000 Lm
- 6200 Lm
- 7000 Lm
CCT
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
- 5700K
- 6500K
CRI
- 80 CRI
- 92 CRI
Color / Finish
- Black
- Custom
- Silver
- White
Voltage
- 120 V
- 240 V
- 277 V
Distribution
- Flood (40° and Greater)
- Narrow Flood (20° - 39°)
Mounting
- Pipe
- Stem
- Surface / Canopy
- Table Base
- Track
- Unistrut
Dimming Protocol
- 0-10 V
- DALI
- DMX
- ELV (Trailing Edge)
- Integral Dimmer
- Lutron EcoSystem
- Triac (Leading Edge)
Dimming Range
- < 1%
Ratings & Compliance
- Build America Buy America Act (BABAA)
- IP20
- Made in America
Warranty
- 5 yr
Efficacy
- 107 lm/w
Lamp Life
- 50000 hrs
